Multi-stage progressive stamping die / mould / tooling for air conditioner motor,Motor stator
rotor laminated
Stamping Capability
A: The min. pitch: 0.5mm
B: Highest stamping speed: 600SPM/min or more
C: Precision: ±0.003mm
D: Rate of hole diameter and thickness 0.85:1
E: Stamping material thickness:0.05-2.0mm
F: zero or less loss of material use.
Motor stator and rotor Stampings
We can manufacture laminations in all grades of silicon steel including fully or semi processed steel in the form of Stators & Rotors, Field & Armatures in loose as well as Interlocked & Auto Riveting Cores, AC/DC motor stator and rotor, induction motor stator, brushless motor stator and rotor, stepper motor stator and rotor,SR motor stator and rotor, PM motor stator and rotor, universinal motor stator and rotor, etc.
Dimensions of EI,Stator and rotor core lamination tooling.with riveting or no riveting,You make stamping ,die here.If the production sheets quantity is no so much.Like some custom-made eltrical stator and rotor core.We also could punch the cores for you too.
METS Precision-Tool uses a variety of 2D and 3D cad/cam Software to develop, design, and plan the layout of our dies. (see below for the full software list & details). We have the resources to build a die for any application. When high volumes of production are expected, we can build a dependable tool with longevity in mind. We can also produce low-cost tools for prototyping and sampling applications. Die protection is always on our mind, and DACO Precision-Tool can build in sensors that will help prevent costly damage to the die.
Stator and rotor core profile
Part thickness | 0.35-0.5-0.65mm | ||
Product Name | Stamping motor core stator , rotor,lamination sheets | ||
Part material | Silicon steel | ||
Grade | B35A300,B50A470,M530-65A,B50A600,B50A800 .M270-50A,M530-65A,M800-50A,50CS1300, 50CS800, 50CS600, 50CS470, 35CS550steel,copper,aluminum | ||
Die type | Interlocked Progressive die ,Auto riveting progressive tool, stamping die,compound die, ect. | ||
cavity | Single / Multi per request | ||
Stacking | loose sheets,or Auto interlocked Stacking | ||
Die material | YG15,YG20,DC53, SKH-9, SKH51, SKD11,D2, | ||
Die use | Water pump, Industrial motor, Fan motor, Generator, Compressor and Car...etc. | ||
Machinery Equipment | Milling, Grinding, Boring, CNC, EDM, WEDM, Forming Machine, Precision flat milling, Saw machine, Punching machine, | ||
Die precision | High precision machining, minimum 0.003mm | ||
Trial out press | 25~160T | ||
First trial sample | 5-10 sets free |
We accept your any request on shipment.By air, by sea,and by Express are acceptable.
By Express | By Air | By Sea | |
West Europe | 3-5 days | 4-6 days | 22-30days |
USA &Canada | 3-4days | 5-6 days | 16-27days |
South Asia | 3-5 days | 3-7 days | 12-20 days |
Japan&South Korea | 2-3 days | 3-4 days | 10-13 days |
Russia | -------- | --------- | 30-40 days |
Packing:
First Step Wrapping by PE film to anti-rust.
Second wooden case without need of fumigation.Or as your required.
FAQ
Q: What’s your manufacture capability?
---- We use Sodick/Charmilles to frabricate die inserts,dimension we can do is +/-0.002mm.
Q: Can you make all the dimensions are according to our design/samples?
---- We can guarantee that all the dimensions are made according to your drawing/sample.Please notice that dimension tolerence we can do is +/-0.003mm.
Q: Did the stamping die suit for my press machine?
--- The stamping die is made according to your press machine’s specification.Before start making die parts,we will send the design for your approval.
Q: What’s your advantage compare with other supplier’s on the market?
---- We are stamping factory,have a team contains die design,making,maintance and stamping production.We know how important the good mold for stamping production.
---- All our engineers are with more than 10 years working experience.They are more professional on precision stamping field.
---- All the die parts we made are by Slow-speed wire EDM,can gurantee the dimension.Many of them make it by middle-speed wire EDM/fast-speed wire EDM
|
