Product Description

Set Square | High Precision Metal Right Angle Ruler

The Set Square | High Precision Metal Right Angle Ruler is a precision measuring and marking tool designed for accurate 90° angle checking, layout, alignment, and inspection. Manufactured from durable metal materials, it provides reliable dimensional stability and long-lasting performance for professional workshops, engineering environments, machining operations, fabrication facilities, and industrial applications.

The set square features a precisely formed right-angle structure that helps users quickly verify perpendicularity and mark accurate reference lines on workpieces. Its rigid construction minimizes deformation during normal use, making it suitable for repeated measuring and inspection tasks.

METS provides OEM and custom metal set square manufacturing based on customer drawings, samples, dimensions, material specifications, and application requirements. Depending on the design, the product can be manufactured using precision stamping, sheet metal forming, laser cutting, CNC machining, bending, and other metalworking processes.

Different materials, thicknesses, dimensions, surface treatments, markings, and structural configurations can be customized. Stainless steel, carbon steel, aluminum, and other metal materials can be selected according to the required strength, corrosion resistance, weight, and working environment.

Whether used as an engineering measuring tool, machining inspection tool, fabrication aid, or custom industrial component, our metal set squares are designed to provide accurate measurement, stable positioning, and consistent performance.

Features

High-Precision 90° Angle - Designed for accurate right-angle measurement and checking.
Durable Metal Construction - Provides good rigidity, dimensional stability, and service life.
Precision Manufacturing - Suitable for demanding measuring, marking, and inspection applications.
Corrosion-Resistant Options - Stainless steel materials and protective finishes can be selected for demanding environments.
Clear Reference Edges - Smooth and accurately formed edges support convenient marking and alignment.
Stable Structure - Rigid construction helps reduce deformation during regular workshop use.
Custom Dimensions - Length, width, thickness, and geometry can be manufactured according to requirements.
OEM Manufacturing - Suitable for custom tool brands, industrial equipment manufacturers, and distributors.
Multiple Surface Finishes - Polishing, brushing, plating, coating, and other finishes are available.
Wide Application Range - Suitable for machining, woodworking, metal fabrication, construction, engineering, and inspection.

Technical Parameters

Product Name	Metal Set Square
Product Type	Right Angle Measuring Ruler
Main Function	90° Angle Measuring, Checking & Marking
Material	Stainless Steel, Carbon Steel, Aluminum, Metal Alloys
Common Stainless Steel	SUS301, SUS304, SUS316, SUS430
Thickness	Customizable according to design
Angle Accuracy	90° precision configuration
Dimensional Tolerance	Customized according to application
Manufacturing Process	Stamping, Bending, Laser Cutting, CNC Machining
Surface Treatment	Polishing, Brushing, Plating, Coating, Passivation
Scale / Marking	Optional, customized
Size	Custom sizes available
Logo	OEM Logo / Laser Marking / Printing
Production Volume	Prototype, Small Batch, Medium & High Volume
Inspection	Dimensional, Visual & Angle Inspection
Application	Workshop, Machining, Fabrication, Engineering, Construction
Customization	Material, Size, Thickness, Marking, Finish, Packaging

Specifications can be customized according to the product design, manufacturing process, and customer requirements.

Applications

Machining & Metalworking

Metal set squares are useful for checking workpiece alignment, verifying 90° angles, and marking reference lines during machining and fabrication. Their rigid construction makes them suitable for repeated workshop operations.

Engineering & Manufacturing

In engineering environments, a precision set square can be used as a basic inspection and layout tool for checking perpendicular relationships between surfaces, components, and assemblies.

Metal Fabrication

Fabricators can use right-angle rulers during cutting, bending, welding, and assembly operations to help maintain accurate positioning and alignment of metal components.

Construction & Installation

Set squares are commonly used for layout and alignment tasks where accurate right angles are required. A durable metal construction can provide better longevity than lightweight plastic alternatives in demanding working environments.

Woodworking

The tool can assist with marking and checking perpendicular lines on wood boards, panels, frames, and other workpieces. Its straight reference edges support repeatable layout work.

Inspection & Quality Control

Precision set squares can be used as an auxiliary inspection tool for checking right-angle relationships and component alignment during manufacturing and quality control procedures.

Educational & Technical Training

Metal set squares can also be used in technical schools, engineering workshops, vocational training, and practical manufacturing education for basic measurement and layout exercises.

Customization

METS provides OEM custom set square manufacturing for customers requiring specific dimensions, materials, markings, or structural designs.

Material Customization

Choose from stainless steel, carbon steel, aluminum, and other suitable metal alloys according to strength, corrosion resistance, weight, and application requirements.

Size & Thickness Customization

The overall length, width, thickness, edge configuration, and geometry can be customized according to technical drawings or samples.

Scale & Marking Customization

Graduated scales, measurement markings, logos, part numbers, and identification information can be added according to customer requirements.

Surface Treatment

Different surface finishes can be selected, including polishing, brushed finish, plating, passivation, coating, and other treatments to improve appearance, corrosion resistance, or surface protection.

Manufacturing Process

Depending on the product structure and required accuracy, METS can select suitable processes such as precision stamping, sheet metal bending, laser cutting, CNC machining, and secondary finishing.

OEM Branding

Custom logos, product identification, packaging labels, and other branding requirements can be incorporated into the finished product for OEM and private-label projects.

Support and Services

METS provides comprehensive support throughout the custom metal set square manufacturing process.

Product Design Review - Evaluation of drawings, dimensions, materials, and manufacturing requirements.
OEM/ODM Manufacturing - Customized production according to drawings, samples, or specifications.
Tooling Development - Custom stamping dies and forming tools can be developed for suitable designs.
Material Selection - Professional recommendations based on strength, corrosion resistance, and application conditions.
Prototype & Sampling - Sample production can be arranged for design and dimensional verification.
Quality Inspection - Dimensional, visual, and angle-related inspections are available.
Surface Treatment - Customized finishing services can be integrated into production.
Packaging Support - Packaging can be designed according to product size and shipping requirements.
Export Service - Suitable solutions for international orders and transportation.
Technical Communication - Continuous communication throughout design, production, inspection, and delivery.

Packing and Shipping

Each metal set square is packed according to its size, quantity, surface finish, and transportation requirements.

Standard packaging options may include protective film, plastic bags, individual cartons, inner boxes, outer cartons, pallets, and wooden cases. Additional protective materials can be used to reduce scratching, bending, and impact during transportation.

For bulk orders, packaging can be optimized to improve space utilization and protect products during long-distance transportation. Customized labels, part numbers, product information, and customer packaging specifications can also be provided.

Shipping methods may include express delivery, air freight, sea freight, or other suitable transportation solutions depending on order quantity, destination, budget, and required delivery time.

Frequently Asked Questions

1. What is a metal set square?

A metal set square is a measuring and marking tool designed primarily for checking and establishing accurate 90° angles. Metal construction provides good rigidity and durability for professional applications.

2. What materials can be used for the set square?

Common options include stainless steel, carbon steel, aluminum, and other metal alloys. Stainless steel is particularly suitable when corrosion resistance and durability are important.

3. Can the set square be customized?

Yes. METS can customize the material, dimensions, thickness, angle configuration, markings, surface finish, logo, and packaging according to customer requirements.

4. Can you add measurement scales?

Yes. Graduated scales, measurement markings, logos, part numbers, and other identification information can be customized according to the product design.

5. Can you manufacture according to our drawings?

Yes. We can manufacture custom metal set squares based on 2D drawings, 3D CAD files, PDF drawings, technical specifications, or physical samples.

6. What manufacturing processes do you use?

Depending on the design, manufacturing may involve metal stamping, precision bending, laser cutting, CNC machining, forming, and secondary finishing processes.

7. Can you provide OEM branding?

Yes. OEM logos, markings, labels, packaging, and other branding requirements can be incorporated into the product according to the project specifications.

8. What surface treatments are available?

Depending on the selected material, options may include polishing, brushing, passivation, plating, coating, and other protective finishes.

9. Is the set square suitable for industrial use?

Yes. The durable metal structure and precision manufacturing make it suitable for machining, metal fabrication, engineering, construction, inspection, woodworking, and industrial workshops.

10. Can you provide samples before mass production?

Yes. Samples can be produced for evaluation and approval before mass production, depending on the project requirements.
