SUS304 Stainless Steel Solar Frame Clip with Tool-Free Snap-in Installation for Corrosion Resistant PV Cable Fixing

Products

SUS304 Stainless Steel Solar Frame Clip with Tool-Free Snap-in Installation for Corrosion Resistant PV Cable Fixing

Detail Information

Product Description

Detail Information

Place of Origin

Brand Name

METS

Product Name:

Solar Cable Clip / PV Wire Clip / Solar Frame Clip

Manufacturing Process:

Progressive Die Stamping & Precision Bending

Material:

Stainless Steel (SUS304 / SUS316) / Spring Steel

Surface Treatment:

Black E-coating / Dacromet / Passivation

Color:

Black / Metallic Silver

Installation:

Tool-free Snap-in Installation

Product Description

Solar Frame Clip | SUS304 Stainless Steel PV Cable Fixing Clip

Product Overview

The Solar Frame Clip | SUS304 Stainless Steel PV Cable Fixing Clip is a high-performance cable management accessory specially designed for photovoltaic (PV) solar panel installation systems. Made from premium SUS304 stainless steel, this solar frame clip provides excellent corrosion resistance, mechanical strength, and long-term durability for outdoor solar applications.

Designed for quick and secure installation, the PV cable fixing clip can be easily attached to solar panel frames, mounting rails, and support structures without additional tools. It helps organize and protect solar cables by preventing loose wires, sagging, abrasion, and potential damage caused by environmental exposure.

With a strong spring structure and precision manufacturing process, the solar frame clip ensures reliable cable retention under various weather conditions, including strong sunlight, rain, wind, and coastal environments. It is widely used in residential, commercial, and utility-scale photovoltaic power systems.

As an experienced metal stamping manufacturer, we provide custom stainless steel solar clips with OEM/ODM services, supporting different sizes, shapes, materials, and surface treatments according to customer requirements.

Key Features

Premium SUS304 Stainless Steel Material: Excellent corrosion resistance, rust prevention, and weather durability for long-term outdoor solar installations.
Strong Cable Fixing Performance: Optimized spring structure provides stable clamping force to securely hold photovoltaic cables while preventing movement and damage.
Tool-Free Installation: Snap-on design allows fast and simple installation directly onto solar module frames, improving efficiency and reducing labor costs.
Excellent Outdoor Durability: Maintains reliable performance under UV exposure, temperature changes, humidity, and heavy weather conditions.
Precision Metal Stamping Manufacturing: Advanced stamping processes ensure accurate dimensions, smooth edges, and consistent quality for large-volume projects.
OEM Customization Available: Customized dimensions, materials, surface finishes, and packaging solutions to meet different solar mounting system requirements.

Technical Specifications

Parameter	Specification
Product Name	Solar Frame Clip
Type	PV Cable Fixing Clip / Solar Panel Cable Clip
Material	SUS304 Stainless Steel / SUS316 Stainless Steel Optional
Manufacturing Process	Precision Stamping, Bending, Forming
Surface Treatment	Natural Stainless Steel Finish, Polishing, Customized
Thickness	0.3mm - 1.5mm (Customized)
Wire Compatibility	2mm² - 6mm² PV Cable (Customized Available)
Installation Method	Snap-On / Tool-Free Installation
Corrosion Resistance	Excellent Rust Resistance
Operating Temperature	-40℃ to +85℃
Application Environment	Outdoor Solar PV Systems
Service Life	20+ Years Outdoor Durability
Tolerance	±0.05mm or Customized
OEM/ODM Service	Available
Quality Standard	ISO9001 Manufacturing Control

Applications

Solar Panel Installation Systems: Photovoltaic module cable management, keeping DC cables organized along solar panel frames.

Residential Solar Power Systems: Rooftop solar installations, home photovoltaic systems, and small-scale renewable energy projects.

Commercial & Industrial Solar Projects: Commercial rooftop PV systems, factory solar power stations, and industrial solar installations.

Utility-Scale Solar Farms: Large solar farms requiring durable cable management solutions for long-term operation.

Solar Mounting Structures: Compatible with aluminum solar frames, mounting rails, brackets, and photovoltaic support systems.

Harsh Environmental Applications: Coastal areas, high-humidity regions, deserts, and other demanding outdoor conditions.

Customization Options

We provide professional OEM and ODM solar frame clip manufacturing services to meet different photovoltaic installation requirements.

Material Selection

SUS304 stainless steel

SUS316 stainless steel for higher corrosion resistance

Other metal materials according to customer requirements

Size & Shape Customization

Customized clip dimensions

Customized cable holding capacity

Customized mounting structure compatibility

Surface Treatment

Brushed finish

Polished finish

Special surface coating upon request

Production Process Customization

Precision stamping

CNC machining

Sheet metal forming

Prototype development

Packaging Customization

Customized labels

Individual packaging

Bulk packaging solutions

Our engineering team can provide design optimization and production support based on customer drawings, samples, or application requirements.

Frequently Asked Questions

Q1: What material is used for the Solar Frame Clip?

The standard material is SUS304 stainless steel, which provides excellent corrosion resistance and durability. SUS316 stainless steel is also available for marine and highly corrosive environments.

Q2: What cables can this PV cable fixing clip hold?

The clip is commonly designed for photovoltaic cables from 2mm² to 6mm², with customized sizes available according to project requirements.

Q3: Can the solar frame clip be customized?

Yes. We provide OEM/ODM services including customized size, shape, material, thickness, surface finish, and packaging.

Q4: Is this clip suitable for outdoor solar installations?

Yes. The stainless steel construction provides excellent resistance against UV radiation, rain, humidity, and temperature changes, making it ideal for outdoor PV systems.

Q5: How is the solar clip installed?

The clip features a snap-fit design that can be directly installed onto solar panel frames or mounting structures without additional tools.
